Description
Hamamatsu C11952 Multiple Four Head Type Photoionizer Controller can operate 4-Photoionizer heads in parallel. It should be convenient to make synchronization.
Applications
- Large size glasses
- High-speed moving objects (films, printed matters, etc.)
Features
- I-PRO function by external contact point, signal output mechanism linked to X-ray emission,
- Momentary operation and alternate ON / OFF operation are switchable,
- I-PRO cuts off power to the L9491 when its circuit is open.
Specifications
| Parameter | Description / Value |
| Input Voltage (AC) | 100 V to 240 V (50 Hz / 60 Hz) |
| Power Output (DC) | 12 V / 0.7 A Max. (per single head) |
| Power Consumption | 50 W Max. |
| Operating Ambient Temperature | 0 °C to +40 °C |
| Storage Temperature | -10 °C to +60 °C |
| Operating Ambient Humidity | Below 60 % |
| Storage Humidity | Below 85 % |
