Description
Hamamatsu L10725-01 Long Life 75W Xenon Lamp has a drastically extended service life compared to previous lamps. This significant increase in service life helps reduce time-consuming maintenance tasks such as lamp replacement and lamp position alignment. Other benefits from using the long life xenon lamp include saving natural resources and a smaller burden on the environment.
Applications
- Semiconductor inspection equipment light source
- Scanner light sources
- Microscope light sources
- Spectrophotometer light sources
- High performance liquid chromatograph (hplc) light sources
Features
- Fused Silica window material,
- Long Life:
- Guaranteed Life: 2000 h,
- Average Life: 3000 h,
- High Stability:
- Fluctuation (p-p): 0.2 % Typ. (1.0 % Max.),
- Drift : ± 0.5 %/h Typ.
- Point Light Source.
Specifications
| Lamp Rating | 75 W |
| Arc Length | 1 mm |
| Lamp Current | 5.7 +/- 0.3 A |
| Lamp Voltage | 13.5 V |
| Window Material | Fused Silica |
| Spectral Distribution (Short) | 185 nm |
| Spectral Distribution (Long) | 2000 nm |
| Light Output Stability Drift Typ. | +/- 0.5 %/h |
| Light Output Stability Fluctuation (p-p) Max. | 1 % |
| Guaranteed Operation Life | 2000 h |
| Average Life | 3000 h |
| Orientation | Vertical +/-15 or Horizontal +/-15 degree |
| Cooling Method | Convection Cooling |
| Supply Voltage Min. | 50 V dc |
| Trigger Voltage | 15 kV |
| Weight | 15 g |
