Description
Hamamatsu L11034 Long Life 150W Xenon Lamp has an output of 240 to 2000 nanometers with Ozone-free silica window material. The guaranteed lifetime is 2000 hours. This significant increase in service life helps reduce time-consuming maintenance tasks such as lamp replacement and lamp position alignment. Other benefits from using the long life xenon lamp include saving natural resources and a smaller burden on the environment.
Applications
- Semiconductor inspection equipment light source
- Scanner light sources
- Microscope light sources
- Spectrophotometer light sources
- High performance liquid chromatograph (hplc) light sources
Features
- Ozone-free Silica window material,
- Long Life:
- Guaranteed Life: 2000 h,
- Average Life: 3000 h,
- High Stability:
- Fluctuation (p-p): 0.2 % Typ. (1.0 % Max.),
- Drift : ± 0.5 %/h Typ.
- Point Light Source.
Specifications
| Lamp Rating | 150 W |
| Arc Length | 2 mm |
| Lamp Current | 8.5 +/- 0.5 A |
| Lamp Voltage | 17 V |
| Window Material | Ozone-free Silica |
| Spectral Distribution (Short) | 240 nm |
| Spectral Distribution (Long) | 2000 nm |
| Light Output Stability Drift Typ. | +/- 0.5 %/h |
| Light Output Stability Fluctuation (p-p) Max. | 1 % |
| Guaranteed Operation Life | 3000 h |
| Average Life | 4000 h |
| Orientation | Vertical +/-15 or Horizontal +/-15 degree |
| Cooling Method | Convection Cooling |
| Supply Voltage Min. | 65 V dc |
| Trigger Voltage | 20 kV |
| Weight | 45 g |
